4500mm2 = (76 dia hole).
Poppet opens between 4 to 6 kPa vacuum for tank protection.
-Aluminium body and poppet.
-Brass cam levers.
-Stainless steel spring and central plunger.
-Nitrile poppet seal and nitrile camlock seal.
Complies with AS5602:2009: Refined petroleum products—Vehicle bottom loading and vapour recovery. (selectivity counter-bore provided).
Complies with Australian SLP.
100mm hose tail.
4” NATO standard camlock.
